额定容量

Capacity

0.05,0.1,0.2,1,2,5,10,15,20,25,30,40,80

100,200,300,500t

输出灵敏度

Rated output

2.0±1%mV/V(0.05,0.1,0.2kN)

3.0±1%mV/V(1~30kN)

零点输出

Zero balance

±1% F.S.

非线性

Non-linearity

0.03%F.S.

滞后

Hysteresis

0.03%F.S.

重复性

Repeatability

0.03%F.S.

蠕变（30min）

Creep(30min)

0.03%F.S.

温度灵敏度漂移

Temp.effect on output

0.02%F.S./10℃

零点温度漂移

Temp.effect on zero

0.02%F.S./10℃

输入电阻

Input impedance

380±10Ω

输出电阻

Output impedance

350±5Ω

绝缘电阻

Insulation

≥5000MΩ/100VDC

激励电压

Recommended excitation

5~15V

最大激励电压

Maximum excitation

20V

温度补偿范围

Compensated temp range

-10~40℃

工作温度范围

Operation temp range

-10~70℃

安全超载

Safe overload

150%F.S.

极限超载

Ultimate overload

200%F.S.

电缆线尺寸

Cable size

φ5×6000mm
